MARINE ANTENNAS AND ACCESSORIES 2024 PRODUCT CATALOG

MARINE ANTENNAS AND ACCESSORIES

1 MOUNTS 15 ACCESSORIES 16 ANTENNAS 6 SAFETY 2 KJM boat safety kits are equipped with components certified by the US Coast Guard, ensuring reliability and compliance with safety standards. These kits provide essential items to keep you and your passengers safe on the water. Stay prepared and enjoy peace of mind knowing you have the necessary tools to handle emergencies effectively. KJM Marine VHF antennas are specifically designed to take the day-in day-out punishment from the smallest run about to the largest of yachts. Incredibly strong construction, Stainless Steel mounting ferrules, UV stabilized polyurethane finish and backed by a 5-Year warranty!

2 New Boat Safety Kits

3 Includes: (4) Adult (Over 90 lbs.) Universal Life Vest (1) Throwable Cushion (1) 3-Flare Kit (1) Signal Horn (1) 5BC Fire Extinguisher without Gauge (1) Anchor Kit 8.5 lb. Fluke with Shackle Galvanized, 3/8” x 100’ 3-Strand Nylon Line, No Chain (2) 3/8” x 15’ Double Braided Nylon Dockline (1) Coast Guard Booklet 42100 Boats up to 19ft

4 (4) Adult (Over 90 lbs.) Universal Life Vest with Bag (1) Throwable Cushion (1) LED ResQFlare with Day Flag (1) Signal Horn (1) 10BC Fire Extinguisher with Gauge (1) Anchor Kit 8.5 lb. Fluke with Shackle Galvanized, 3/8” x 150’ 3-Strand Nylon Line, 1/4” x 6’ Galvanized Chain with Shackle (2) 3/8” x 20’ Double Braided Nylon Dockline (1) Coast Guard Booklet Includes: 42101 Boats 20ft-25ft

5

6 Quality & Performance Marine VHF Antennas and Mounts

7 A441-VSS 3 ft./3dB KJM marine antennas result from decades of continuous improvement of design and manufacturing and close collaboration with marine professionals. When selecting a KJM antenna, rest assured that you are getting the best value for your money and relax and know that your antenna is built to last. A1791-V 17.5 ft./9dB A786-V 8 ft./6dB A431-V 4 ft./3dB A1791-V 17.5 ft./9dB A431-VSS 3 ft./3dB A431-AIS 4 ft./3dB A431-VB 4 ft./3dB A786-VB 8 ft./6dB A1791-V 17.5 ft./9dB A862-AMFM 8 ft.

8 A431-V (White) / A431-VB (Black) Marine VHF Antenna 4 foot / 3dB Gain A431-V marine VHF antenna includes 20’ of low-loss RG-8/X cable permanently attached to the antenna and a high-quality FME, non-solder type connector for a hassle-free, professional installation. The A431-V uses copper and brass elements for maximum range and efficiency, all enclosed in a stylish UV resistant radome with stainless steel ferrule. Used with standard 1”-14 mounts, this thick-walled fiberglass antenna is well suited for use on hardtops or T-tops on smaller vessels, where the pounding of wave motion can put additional stress on a taller antenna. All KJM antennas are backed by a 5-Year warranty, so you can communicate with confidence! Features: • Single 4’ section, 3db gain • Brass and copper elements for maximum range and efficiency • Stainless steel ferrule with standard 1″-14 thread • 20’ RG-8/X low-loss cable • FME, non-solder type connection included • Suggested mount: M101 • 5 Year warranty Specifications Frequency Range Gain Average Housing Impedance Max. Input Power Polarization Elements SWR Cable Supplied Connector DC Ground Warranty Marine VHF Band, 156.8 MHz, +- 3 MHz @ 2.0:1 3dB 4’ Fiberglass with Stainless Steel Ferrule 50 Ohms 50 Watts Vertical Brass & Copper Less than 1.5:1 at 156.8Mhz 20’ RG8/X FME, non-solder type included Not grounded: The antenna will read open on continuity test 5 Years

9 A431-AIS Marine AIS Antenna 4 foot/3dB Gain The new A431-AIS marine AIS antenna builds on the success of the A430-AIS and includes 20’ of low-loss RG-8/X cable permanently attached to the antenna and a high quality FME, non-solder type connector for a hassle-free, professional installation. The A431-AIS uses copper and brass elements for maximum range and efficiency, all enclosed in a stylish UV resistant radome with stainless steel ferrule. Used with standard 1”-14 mounts, this thick-walled fiberglass antenna is perfect for stand-alone AIS applications. All KJM antennas are backed by a 5-Year warranty, so you can communicate with confidence! Features: • Single 4’ section, 3db gain • Brass and copper elements for maximum range and efficiency • Stainless steel ferrule with standard 1″-14 thread • 20’ RG-8/X low-loss cable • FME, non-solder type connector included • Suggested mount: M101 • 5 Year warranty Specifications Frequency Range Gain Average Housing Impedance Max. Input Power Polarization Elements SWR Cable Supplied Connector DC Ground Warranty Marine VHF Band, 162 MHz, +-3MHz @ 2.0:1 3dB 4’ Fiberglass with Stainless Steel Ferrule 50 Ohms 50 Watts Vertical Brass & Copper Nominally 1.5:1 at 162MHz 20’ RG8/X FME, non-solder type included Grounded: The antenna will read shorted on continuity test 5 Years

10 A431-VSS Marine VHF Antenna 3 foot / 3 dB Gain A431-VSS is a high performance 3-foot, light weight, low-profile, stainless-steel marine VHF antenna. Specifically designed for sailboat masthead mounting. Supplied with a stainless steel, L-shaped bracket. Features: • Stainless Steel 3’ Marine VHF Antenna with 3dB Gain • Supplied with stainless steel L-shaped mounting bracket • Brass Radiators for Max. Transmit & Receive Performance • 5 Year Warranty Specifications Gain Average Max. Input Power Impedance Polarization SWR Bandwidth Ferrule DC Ground Warranty 3dB 50 Watts 50 Ohms Vertical Nominally 1.5:1 at 156.8Mhz 7 MHz within 2.0:1 VSWR Chrome-plated brass canister Not grounded: The antenna will read open on continuity test 5 Years

11 A441-VSS Marine VHF Antenna 3 foot/ 3 dB Gain A441-VSS is a high performance 3-foot, light weight, low-profile stainless steel marine VHF antenna ideal for sailboat mastheads and small powerboats. Supplied with 15’ of low loss RG-58 coax cable and terminated with PL-259 solder-type connector. Made with a 1”-14 stainless steel ferrule for straight or ratchet mounts. Features: • Stainless Steel 3’ Marine VHF Antenna with 3dB Gain • 1”-14 Stainless Ferrule • Brass Radiators for Max. Transmit & Receive Performance • Supplied with 15’ of Low Loss RG-58 & Terminated with PL-259 solder-type connector • 5 Year Warranty Specifications Gain Average Max. Input Power Impedance Polarization SWR Bandwidth Ferrule Coax Supplied Cable Type DC Ground Warranty 3dB 50 Watts 50 Ohms Vertical Nominally 1.5:1 at 156.8 MHz 7 MHz within 2.0:1 VSWR Chrome-plated brass canister 15’ of RG-58 PL-259 solder type, not installed No DC ground 5 Years

12 A786-V (White) / A786-VB (Black) Marine VHF Antenna 8 foot / 6 dB Gain A786-V antenna is a high-performance 8-foot VHF Marine antenna. Supplied with 20’ of low loss RG-8X and terminated with FME connectors make the A786-V antenna easy to install as there is no soldering needed. Features: • 8’ Marine VHF Antenna with 6dB Gain • 1”-14 Stainless Ferrule • Brass Radiators for Maximum Transmit & Receive Performance • FME connectors, non-solder type included • Supplied with 20’ of Low Loss RG-8X & Terminated with FME connectors • 5 Year Warranty Specifications Bandwidth Gain Average Ferrule Impedance Max. Input Power Polarity SWR Coax Supplied Connector DC Ground 3 MHz within 2.0:1 VSWR 6dB Stainless Steel 50 Ohms 100 Watts Vertical Nominally 1.5:1 at 156.8 MHz 20 ft of RG-8/X FME connectors, non-solder type DC Grounded - The antenna will read shorted on continuity test

13 A862-AMFM Marine AM/FM Antenna 8 foot Pull in those distant stations with the new A862-AMFM marine grade antenna. The A862-AMFM includes 20’ of low-loss RG-62 cable with the standard Motorola connector to plug directly into your vessel’s stereo. The A862-AMFM uses copper and brass elements for maximum range and efficiency, all enclosed in a stylish UV resistant radome with stainless steel ferrule for use with standard 1”-14 mounts. A match for the A862-V VHF antenna, this thick-walled fiberglass antenna is built to withstand the rigors of use on hardtops, T-tops, and radar arches. All KJM antennas are backed by a 5-Year warranty, so you can communicate with confidence! Features: • Single 8’ section • Brass and copper elements for maximum range and efficiency • Stainless steel ferrule with standard 1″-14 thread • 20’ RG-62 low-loss cable • Motorola-type connector pre-installed • Suggested mount: M101 • 5 Year warranty Specifications Frequency Range Housing Impedance Polarization Elements Cable supplied Connector Warranty AM (500-1600 KHz); FM (88-108 MHz) 8’ White Fiberglass with stainless steel ferrule 93 Ohms Vertical Brass & Copper 20’ RG-62 Motorola type, pre-installed 5 Years

14 A1791-V Marine VHF Antenna 17.5 foot / 9dB Gain A worthy replacement for the A1790-V, the new A1791-V marine VHF antenna is a 9db two-piece antenna rugged enough for commercial use but attractive enough for the finest of yachts. It includes 20’ of low-loss RG-8/X cable permanently attached to the antenna and a high-quality solder-type PL-259 connector for a professional installation. The A1791-V uses phased 1/2-wave copper and brass elements in a collinear array with choking sleeve to suppress cable radiation, allowing for maximum range and efficiency. The elements are enclosed in a stylish UV resistant radome with stainless steel ferrule for use with standard 1”-14 mounts. Features: • Two 105” sections (17.5’ total), 9dB gain • Brass and copper elements for maximum range and efficiency • Stainless steel ferrule with standard 1″-14 thread • 20’ RG-8/X low-loss cable • Solder-type PL-259 connector • 5 Year warranty Specifications Frequency Range Gain Average Housing Impedance Max. Input Power Polarization Elements SWR Cable Supplied Connector DC Ground Warranty Marine VHF Band, 156.8 +- 3 MHz @ 2.0:1 9dB 17.5’ Two-Piece White Fiberglass with Stainless Steel Ferrule and Couplings 50 Ohms 150 Watts Vertical Brass & Copper Nominally 2.0:1 at 156.8 MHz 20’ RG8/X PL-259, solder type, not installed Not grounded: The antenna will read open on continuity test 5 Years

15 Features: • Stainless Steel • Versatile • Can be used for mounting to vertical or horizontal surfaces - deck or bulkhead - and adjust to a slanted surface • Built to withstand harsh marine environment Specifications Specifications Material Size Material Size Heavy-Duty Stainless Steel 1 - 14 TPO thread, male Stainless steel 4-inches tall; 1 - 14 thread M101 M201

16 AC201 VHF/AIS Extension Cable AC301 AM/FM Extension Cable Features: • Designed for low signal loss • Made to withstand the rigors of the boating environment • Easy Route Coaxial Cable with FME connector (AC201 only) Specifications Length Connector Compatibility 20’ RG-62 Motorola male/female AM/FM Antenna Specifications Length Connector Compatibility 20’ RG-8X FME connectors and adapter VHF/AIS Antenna Specifications Type Compatibility FME Coax cable to PL-259 adapter VHF/AIS Antenna FME-PL259-1 FME to PLE-259 Adapter Accessories for our Marine VHF and AM/FM antennas

17

Call 1-866-SEAWIDE Online At seawide.com Follow Us At @Seawide Exclusively Distributed By:
